LDPC Decoder Applications
This website gives an overview of all standards that apply LDPC codes. The standards are categorized by the organization that published the standard. Furthermore, draft standards are listed. Just click on the standard you want to know more about.
Let us know if anything is missing!
3GPP
3GPP
5G-NR
5G NR is the mobile broadband standard of the 5th generation. A new
rate compatible structure for LDPC codes are employed for channel coding
to fulfill the broad applications supported by the standard.
Creonic’s 5G LDPC Decoder IP Core provides a perfect solution for this
new LDPC structure with high level of flexibility while maintaining high
throughput and low latency as required by the standard.
Standard | Low density parity check coding for 5G-NR |
Organization | 3GPP (3rd Generation Partnership Project) |
Publication | 5G-NR Physical layer procedures for data (3GPP TS 38.214 version 15.10.0 Release 15) |
Documents | 3GPP TS 38.214 version 15.10.0 Release 15 |
Applications | 5G modem chipset for base station (BS) or user equipment (UE) |
IP Core | Creonic LDPC Decoder and Encoder |
LDPC Codes | 3978
Basegraph 1: code rate 22/68 to 22/26 Basegraph 2: code rate 10/52 to 10/14 Lifting size set 0 to 7 |
ETSI
ETSI
DVB-S2X
DVB-S2X is the next generation satellite transmission standard which is an extended version of its well-established predecessor DVB-S2. The new specification allows for spectral efficiency gains of up to 50% by offering lower roll-off factors, higher modulations and a finer code rate granularity compared to DVB-S2.
Standard | DVB-S2X |
Second generation framing structure, channel coding and modulation systems for Broadcasting, Interactive Services, News Gathering and other broadband satellite applications. | |
Organization | ETSI |
Publication | 2014 |
Documents | BlueBook A83-2 / EN302307-2 |
Applications | Satellite Communication (Broadcasting, DSNG, ...) |
IP Cores | Creonic DVB-S2X Demodulator IP Core |
Creonic DVB-S2X LDPC/BCH Decoder IP Core | |
LDPC Codes | 55 |
Block Length | Submatrix Size | Code Rates |
16200 | 360 | 1/5, 1/3, 2/5, 4/9, 3/5, 2/3, 11/15, 7/9, 37/45, 8/9 (DVB-S2)
11/45, 4/15, 14/45, 7/15, 8/15, 26/45, 32/45 (DVB-S2X) |
64800 | 360 | 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 (DVB-S2)
2/9, 13/45, 9/20, 90/180, 96/180, 11/20, 100/180, 26/45, 18/30, 28/45, 23/36, 116/180, 20/30, 124/180, 25/36, 128/180, 13/18, 22/30, 135/180, 7/9, 154/180 (DVB-S2X) |
DVB-S2
In 2005 DVB-S2 became the first standard to adopt LDPC codes. Today it is quite popular and the de-facto standard for high-speed satellite communication. The standard defines four different system configurations and application areas: broadcast services, interactive services, digital satellite news gathering (DSNG), and professional services.
The properties of the LDPC codes in this standard make the hardware implementation of the LDPC decoder quite challenging. With 64800 bits the DVB-x2 series offers the longest LDPC codeword sizes, consuming quite a bit of memory in a hardware realization. Throughputs are typically less than 100 Mbit/s on the air interface. Together with an outer BCH decoder, the forward error correction of the DVB-S2 standard achieves an outstanding error correction performance.
Standard | DVB-S2 |
Second generation framing structure, channel coding and modulation systems for Broadcasting, Interactive Services, News Gathering and other broadband satellite applications. | |
Organization | ETSI |
Publication | 2005 |
Documents | ETSI EN 302 307 |
Applications | Satellite Communication (Broadcasting, DSNG, ...) |
IP Cores | Creonic DVB-S2 LDPC/BCH Encoder and Decoder IP Core |
LDPC Codes | 21 |
Block Length | Submatrix Size | Code Rates |
16200 | 360 |
1/5, 1/3, 2/5, 4/9, 3/5, 2/3, 11/15, 7/9, 37/45, 8/9 |
64800 | 360 |
1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 |
DVB-T2
DVB-T2 is the successor of DVB-T. It was published in 2009 and integrates a subset of the LDPC codes as defined in DVB-S2. Two LDPC codes (block length 16200, code rate 3/5 and block length 64800, code rate 2/3) were, however, replaced. While DVB-S2 uses LDPC and BCH coding only for payload data (so-called baseband frames, BBFrames), DVB-T2 uses two LDPC codes (16200 bits, rate 1/5 and rate 4/9) for the signalling of the current configuration of the DVB-T2 system.
Standard | DVB-T2 |
Frame structure channel coding and modulation for a second generation digital terrestrial television broadcasting system. | |
Organization | ETSI |
Publication | 2009 |
Documents | ETSI EN 302 755 |
Applications | Terrestrial television broadcasting |
LDPC Codes | 13 |
Block Length | Submatrix Size | Code Rates |
16200 | 360 |
1/5, 4/9, 3/5, 2/3, 11/15, 7/9, 37/45 |
64800 | 360 |
1/2, 3/5, 2/3, 3/4, 4/5, 5/6 |
DVB-T2-Lite
The latest version of the DVB-T2 standard (V 1.3.1, Annex I) contains a new lightweight profile. The main objective of DVB-T2-Lite is the reduction of receiver complexity so that applications like mobile broadcasting become feasible. Therefore only the short LDPC frames with 16200 bits are contained within DVB-T2-Lite, resulting in a decreased LDPC/BCH decoder complexity.
Standard | DVB-T2-Lite |
Frame structure channel coding and modulation for a second generation digital terrestrial television broadcasting system. | |
Organization | ETSI |
Publication | 2012 |
Documents | ETSI EN 302 755, V1.3.1 |
Applications | Mobile broadcasting |
LDPC Codes | 7 |
Block Length | Submatrix Size | Code Rates |
16200 | 360 | 1/5, 1/3, 2/5, 4/9, 3/5, 2/3, 11/15 |
DVB-C2
Standard | DVB-C2 |
Frame structure channel coding and modulation for a second generation digital transmission system for cable systems. | |
Organization | ETSI |
Publication | 2010 |
Documents | ETSI EN 302 769 |
Applications | Digital transmission for cable networks. |
IP Cores | Creonic DVB-C2 LDPC/BCH Decoder IP Core |
LDPC Codes | 11 |
Block Length | Submatrix Size | Code Rates |
16200 | 360 |
4/9, 2/3, 11/15, 7/9, 37/45, 8/9 |
64800 | 360 |
2/3, 3/4, 4/5, 5/6, 9/10 |
GMR-1
GEO-Mobile Radio (GMR) is a standard for satellite telephony that follows the GSM standard in many ways. Only the three lower layers of the OSI model differ between GMR and GSM (for GMPRS only the two lowest layers).
Two versions of the standard exist: GMR-1 (ETSI TS 101 376) and GMR-2 (ETSI TS 101 377). For GMR-1 three releases exist. Release 2 and Release 3 of GMR-1 adopted LDPC codes in 2008 and 2009, respectively. The standard is characterized by low throughput requirements of less than 1 Mbit/s. Puncturing, shortening, and repeating is applied in order to obtain different code rates and block lengths from the parity check matrices.
Standard | GMR-1 Release 2 (GMPRS-1), |
GMR-1 Release 3 (GMR-3G) | |
Organization | ETSI |
Publication | 2008 (GMPRS-1), |
2009 (GMR-3G) | |
Documents | ETSI TS 101 376-5-3 V2.3.1 (GMPRS-1), |
ETSI TS 101 376-5-3 V3.1.1 (GMR-3G) | |
Applications | Satellite telephony |
IP Core | Creonic GMR-1 LDPC Decoder IP Core |
LDPC Codes | 18 |
Block Length | Submatrix Size | Code Rates |
950 | 19 |
4/5 |
960 | 16 |
9/10 |
976 | 61 |
1/2 |
1908 | 53 |
2/3 |
1920 | 32 |
4/5, 9/10 |
2400 | 50 |
3/4 |
2400 | 48 |
4/5 |
4440 | 74 |
2/3, 4/5 |
4464 | 62 |
1/2 |
4480 | 64 |
9/10 |
8880 | 74 |
2/3, 4/5, 9/10 |
11100 | 74 |
4/5 |
11136 | 87 |
3/4 |
IEEE
IEEE
IEEE 802.3 (10 GBASE-T)
The IEEE 802.3 standard defines 10 gigabit Ethernet and was first published in 2002. In 2006 the IEEE 802.3an standard was released as an amendment to IEEE 802.3-2005. This amendment (10 GBASE-T) defines the 10 gigabit transmission over shielded or unshielded twisted pair cables for distances of up to 100 m. It uses LDPC codes for forward error correction. The IEEE 802.3an amendment was consolidated into IEEE 802.3-2008.
10 GBASE-T contains a special class of LDPC codes (so-called Reed-Solomon code-based LDPC codes or RS-LDPC codes). A Reed-Solomon code is used to define the generator matrix of the LDPC code. The LDPC code construction method guarantees that no cycles of length four are contained within the Tanner graph. Since the structure of the parity check matrix differs from all other standardized LDPC codes, different decoder architectures become mandatory.
Standard |
IEEE 802.3an-2006, IEEE 802.3-2008 |
Local and metropolitan area networks — Specific requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications |
|
Organization | IEEE |
Publication |
2006 (IEEE 802.3an-2006 as amendment to IEEE 802.3-2005), 2008 |
Documents | |
Applications | Local and metropolitan area networks (LAN/MAN) |
LDPC Codes | 1 |
Block Length | Submatrix Size | Code Rates |
2048 | N/A |
1723/2048 |
IEEE 802.11 (WiFi)
IEEE 802.11n is the successor of the IEEE 802.11a/b/g standards. It is particularly designed for higher throughputs. In contrast to the previous IEEE 802.11 standards, 11n can use multiple antennas (MIMO) allowing for the transmission of multiple data streams in parallel. The throughput of each data stream can be as high as 150 Mbit/s on the air interface. With a maximum of four antennas up to 600 Mbit/s are defined within the standard.
IEEE 802.11n defines twelve LDPC codes. Convolutional coding is mandatory, usage of LDPC coding is optional. The IEEE 802.11n codes are reused within the IEEE 802.11ac standard that is intended to further increase the transmission speed.
Standard |
IEEE 802.11n-2009 IEEE 802.11-2012 |
Local and metropolitan area networks — Specific requirements Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications Amendment 5: Enhancements for Higher Throughputs |
|
Organization | IEEE |
Publication | 2009 (IEEE 802.11n-2009 as amendment to IEEE 802.11-2007) |
Documents | |
Applications | Local and Metropolitan Area Networks (WLAN/WMAN) |
IP Core | Creonic IEEE 802.11n LDPC Decoder IP Core |
LDPC Codes | 12 |
Block Length | Submatrix Size | Code Rates |
648 | 27 |
1/2, 2/3, 3/4, 5/6 |
1296 | 54 |
1/2, 2/3, 3/4, 5/6 |
1944 | 81 |
1/2, 2/3, 3/4, 5/6 |
IEEE 802.15.3c (60 GHz PHY)
IEEE 802.15.3-2003 is a standard for high data rate wireless personal area networks (WPAN). The IEEE 802.15.3c-2009 amendment describes an alternative PHY layer to the IEEE 802.15.3-2003 standard. The new mmWave PHY layer operates in the 60 GHz band (57 - 64 GHz) and allows for air throughputs of up to 5 Gbit/s. The standard uses LDPC codes for these high data rate modes. In particular, the single carrier (SC) mode and the high speed interface (HSI) mode use LDPC codes.
The standard defines five LDPC codes with two block lengths. In order to satisfy the high throughput requirements, special decoder architectures with an increased parallelism compared to other standards become mandatory.
Standard |
IEEE 802.15.3c-2009 |
Local and metropolitan area networks — Specific requirements Part 15.3: Wireless Medium Access Control (MAC) and Physical Layer (PHY) Specifications for High Rate Wireless Personal Area Networks (WPANs) Ammendment 2: Millimeter-wave-based Alternative Physical Layer Extension |
|
Organization | IEEE |
Publication | 2009 (as amendment to IEEE 802.15.3-2003)/td> |
Documents | |
Applications | High Rate Wireless Personal Area Networks (WPAN) |
IP Core | Creonic IEEE 802.15.3c LDPC Decoder |
LDPC Codes | 5 |
Block Length | Submatrix Size | Code Rates |
672 | 21 |
1/2, 3/4, 5/8, 7/8 |
1440 | 96 |
14/15 |
IEEE 802.16 (Mobile WiMAX)
Along with DVB-S2 and the drafts of IEEE 802.11n, Mobile WiMAX (Worldwide Interoperability for Microwave Access) was one of the first standards to adopt LDPC codes for forward error correction. Mobile WiMAX was first defined in IEEE 802.16e-2005 as an amendment to IEEE 802.16-2004, and later consolidated into IEEE 802.16-2009. The throughputs of WiMAX systems are typically much less than 100 Mbit/s. Using the LDPC codes is optional.
The standard offers the highest block length flexibility of all standards that apply LDPC codes. Overall 19 block lengths are defined. Each block length comes with four code rates. For two code rates (rate 2/3 and rate 3/4 the standard defines two different LDPC codes with minor differences in error correction performance. All in all, 114 LDPC codes are contained within the WiMAX standard. However, only six parity check matrices are used to derive all other matrices. The usage of LDPC coding is optional, only convolutional coding is mandatory.
The same LDPC codes are used within the IEEE 802.22 and ITU-T G.hn standards, see below.
Standard |
IEEE 802.16e-2005, IEEE 802.16-2009 |
Local and metropolitan area networks Part 16: Air Interface for Fixed and Mobile Broadband Wireless Access Systems |
|
Organization | IEEE |
Publication |
2006 (IEEE 802.16e-2005 as amendment to IEEE 802.16-2004), 2009 |
Documents | |
Applications | Local and Wireless Metropolitan Area Networks (WLAN/WMAN) |
LDPC Codes | 114 |
Block Length | Submatrix Size | Code Rates |
576 | 24 |
1/2, 2/3 (2x), 3/4 (2x), 5/6 |
672 | 28 |
1/2, 2/3 (2x), 3/4 (2x), 5/6 |
768 | 32 |
1/2, 2/3 (2x), 3/4 (2x), 5/6 |
... | ... |
... |
2208 | 92 |
1/2, 2/3 (2x), 3/4 (2x), 5/6 |
2304 | 96 |
1/2, 2/3 (2x), 3/4 (2x), 5/6 |
IEEE 802.22 (WRAN)
IEEE 802.22 is a standard for wireless broadband access that uses the so-called white spaces between occupied channels in the TV frequency spectrum. The aim of the standard is to bring broadband access to low population density areas. The maximum data rate is about 20 Mbit/s. Due to its cognitive radio techniques, it has the potential to be applied in many regions worldwide.
As with ITU-T G.hn the standard uses the WiMAX (IEEE 802.16) LDPC codes as LDPC code basis. Compared to WiMAX two new block lengths are introduced (384 and 480 bits). Furthermore, it no longer contains two different codes for code rate 2/3 and code rate 3/4. Instead it adopted the codes 2/3B and 3/4A only. So despite the new block lengths, the number of LDPC codes decreased from 114 for WiMAX to 84 for IEEE 802.22. LDPC coding is optional, only convolutional coding is mandatory.
Standard | IEEE 802.22-2011 |
Wireless Regional Area Networks (WRAN)—Specific requirements Part 22: Cognitive Wireless RAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications: Policies and Procedures for Operation in the TV Bands |
|
Organization | IEEE |
Publication |
2011 |
Documents | |
Applications | Wireless Regional Area Networks (WRAN) |
LDPC Codes | 84 |
Block Length | Submatrix Size | Code Rates |
384 | 16 |
1/2, 2/3, 3/4, 5/6 |
480 | 20 |
1/2, 2/3, 3/4, 5/6 |
576 | 24 |
1/2, 2/3, 3/4, 5/6 |
... | ... |
... |
2208 | 92 |
1/2, 2/3, 3/4, 5/6 |
2304 | 96 |
1/2, 2/3, 3/4, 5/6 |
Miscellaneous
Miscellaneous
ATSC 3.0
Advanced Television Systems Committee (ATSC) standards are a set of standards developed by the Advanced Television Systems Committee for digital television transmission over terrestrial, cable, and satellite networks.
The standard describes 24 LDPC codes that are similar to those of DVB-S2/-T2/-C2. The codes are concatenated with an inner BCH encoder.
Standard | |
Organization | ATSC |
Publication | |
Documents | |
Applications | Digital TV |
IP Core | Contact us! |
LDPC Codes | 24 |
Block Length | Information Word | Submatrix Size | Code Rates |
64800 | 8640 | 360 | 2/15 |
64800 | 12960 | 360 | 3/15 |
64800 | 17280 | 360 | 4/15 |
64800 | 21600 | 360 | 5/15 |
64800 | 25920 | 360 | 6/15 |
64800 | 30240 | 360 | 7/15 |
64800 | 34560 | 360 | 8/15 |
64800 | 38880 | 360 | 9/15 |
64800 | 43200 | 360 | 10/15 |
64800 | 47520 | 360 | 11/15 |
64800 | 51840 | 360 | 12/15 |
64800 | 56160 | 360 | 13/15 |
16200 | 2160 | 360 | 2/15 |
16200 | 3240 | 360 | 3/15 |
16200 | 4320 | 360 | 4/15 |
16200 | 5400 | 360 | 5/15 |
16200 | 6480 | 360 | 6/15 |
16200 | 7560 | 360 | 7/15 |
16200 | 8640 | 360 | 8/15 |
16200 | 9720 | 360 | 9/15 |
16200 | 10800 | 360 | 10/15 |
16200 | 11880 | 360 | 11/15 |
16200 | 12960 | 360 | 12/15 |
16200 | 14040 | 360 | 13/15 |
DOCSIS 3.1
Data Over Cable Service Interface Specification is an international telecommunications standard that permits the addition of high-bandwidth data transfer to an existing cable TV (CATV) system.
The standard describes six LDPC codes, wherof one is taken from DVB-C2. For some codes puncturing and shortening is applied in order to obtain different block sizes and code rates.
Standard | Data-Over-Cable Service Interface Specifications DOCSIS® 3.1 |
Physical Layer Specification | |
Organization | CableLabs |
Publication | 2013 (first release) |
Documents | CM-SP-PHYv3.1-I07-150910 |
Applications | Data transfer over existing cable TV systems |
IP Core | Creonic DOCSIS 3.1 LDPC Decoder IP Cores |
LDPC Codes | 6 |
Block Length | Information Word | Submatrix Size | Code Rates |
160 | 80 | 16 | 1/2 |
480 | 288 | 48 | 3/5 |
16200 (DVB-C2) | 14400 | 360 | 8/9 |
1120 | 840 | 56 | 3/4 |
5940 | 5040 | 180 | 28/33 |
16200 | 14400 | 360 | 8/9 |
CCSDS
The CCSDS (The Consultative Committee for Space Data Systems) published an "experimental specification" for near-earth and deep space communication in 2007. The document was contributed to CCSDS by NASA (National Aeronautics and Space Administration). In 2011 the LDPC codes were adopted by a blue book as "recommended standard".
The documents describe ten LDPC codes, one optimized for near-earth communication (block length 8176), and all others optimized for deep space communication. The block lengths of the deep space codes were selected such that three lengths of information words exist (1024, 4096, and 16384).
Standard | Low Density Parity Check Codes for Use in Near-Earth and Deep Space Applications, Orange Book, Issue 2, Experimental Specification. |
TM Synchronization and Channel Coding, Blue Book, Issue 2, Recommended Standard. | |
Organization | CCSDS (The Consultative Committee for Space Data Systems) |
Publication |
2007 (Orange Book) 2011 (Blue Book) |
Documents | |
Applications | Near-Earth and deep space communication |
IP Core | Creonic CCSDS LDPC Encoder and Decoder |
LDPC Codes | 10 |
Block Length | Information Word | Submatrix Size | Code Rates |
8176 | 7154 | 511 | 7/8 |
1280 | 1024 | 128 | 4/5 |
1536 | 1024 | 256 | 2/3 |
2048 | 1024 | 512 | 1/2 |
5120 | 4096 | 512 | 4/5 |
6144 | 4096 | 1024 | 2/3 |
8192 | 4096 | 2048 | 1/2 |
20480 | 16384 | 2048 | 4/5 |
24576 | 16384 | 4096 | 2/3 |
32768 | 16384 | 8192 | 1/2 |
CMMB
The Chinese Mobile Multimedia Broadcasting (CMMB) standard was published in 2006 by the Chinese State Administration of Radio, Film, and Television (SARFT). The standard is intended for handheld devices and supports data rates of up to 16 Mbit/s.
Two LDPC codes are defined, both of the same block length. While in DVB-x2 an outer BCH decoder is applied, CMMB concatenates the LDPC decoder with an outer Reed-Solomon decoder. Each LDPC code can be concatenated with three diffferent RS-Codes of different rates. But it is also possible to omit the outer RS-Code.
Block Length | Submatrix Size | Code Rates |
9216 | 256 | 1/2, 3/4 |
DTMB (DMB-T/H)
Digital Terrestrial Media Broadcast (DTMB) is a Chinese standard for digital broadcasting. Unlike CMMB, it is intended for fixed terminals and supports HDTV transmission. It will replace the analog TV transmission in China. Data rates of up to 32 Mbit/s are supported.
The standard defines three LDPC codes of the same block length. The forward error correction uses an outer BCH decoder. A specialty of the defined codes is the submatrix size of 127. This is a prime number that has some negative influence on an efficient hardware decoder realization.
Standard |
DTMB |
Framing structure, channel coding and modulation for digital television terrestrial broadcasting system | |
Organization | SAC (Standardization Administration of China) |
Publication | 2006 |
Documents | GB 20600-2006 |
Applications | Digital Broadcast (terrestrial / handheld) |
LDPC Codes | 3 |
Block Length | Submatrix Size | Code Rates |
7493 | 127 | 2/5, 3/5, 4/5 |
ITU-T G.hn (G.9960)
G.hn is the name for home grid technologies defined by the International Telecommunication Unit (ITU). The recommendation G.9960 defines physical layer and system architecture while recommendation G.9961 defines the data link level. The standard defines the communication over three different types of wires: coaxial cables (cable networks), telephone lines, and power lines. G.hn systems achieve throughputs of up to 1 Gbit/s.
The standard uses a subset of the WiMAX (IEEE 802.16) LDPC codes in order to derive its own LDPC codes with different block lengths. While the WiMAX codes are defined for a block length of 2304, the G.hn standard defines seven different block lengths with a total of three different code rates (rate 1/2, rate 2/3, rate 5/6). The shortest block length is used for header information only, while all other block lengths hold payload information. The standard defines puncturing patterns to increase the code rate beyond rate 5/6. By the removal of parity bits from the highest rate codes before transmission, the code rates 16/18 and 20/21 are obtained.
Standard |
ITU-T G.hn |
Series G: Transmission Systems and Media, Digial Systems and Networks G.9960: Unified high-speed wire-line based home networking transceivers - System architecture and physical layer specification |
|
Organization | ITU (International Telecommunication Unit) |
Publication | 2009 |
Documents | ITU-T G.9960 |
Applications | Wired home networking (e.g., power line communication) |
LDPC Codes | 7 |
Block Length | Information Word | Submatrix Size | Code Rates |
336 | 168 | 14 | 1/2 |
1152 | 960 | 48 | 5/6 |
1440 | 960 | 60 | 2/3 |
1920 | 960 | 80 | 1/2 |
5184 | 4320 | 216 | 5/6 |
6480 | 4320 | 270 | 2/3 |
8640 | 4320 | 360 | 1/2 |
WiMedia 1.5 UWB
The WiMedia Alliance is a non-profit organization that promotes and certifies ultra-wide band (UWB) technologies. In version 1.5 of its physical layer, the WiMedia standard adopted LDPC codes for high data rates (payload throughputs of up to 1 Gbit/s). For lower rates, convolutional codes are used. The standard defines two block lengths: 1200 and 1320. The long blocks are obtained by a re-encoding of the short blocks with a rate 10/11 LDPC code. These additional parity bits are transmitted on the guard tones of an OFDM symbol for throughputs of 640 Mbit/s and above. The receiver, however, is allowed to ignore these 120 additional parity bits for decoding.
Standard |
MultiBand OFDM Physical Layer Specification |
PHY Specification: Final Deliverable 1.5 | |
Organization | WiMedia Alliance |
Publication | 2009 |
Documents | WiMedia PHY Specification 1.5 |
Applications | Wireless Personal Area Networks (WPAN) |
IP Core | Creonic WiMedia 1.5 LDPC Encoder/Decoder IP Core |
LDPC Codes | 8 |
Block Length | Submatrix Size | Code Rates |
1200 | 30 | 1/2, 5/8, 3/4, 4/5 |
1320 | 30 | 5/11, 25/44, 15/22, 8/11 |
Drafts
Drafts
DVB-NGH
DVB-NGH is a draft standard for digital broadcasting systems for handheld devices. Parts of the standards are similar to DVB-T2-Lite. Hence, the maximum block length of the LDPC codes is 16200 bits. Seven new LDPC codes were added to the DVB family of standards (16200 bit codewords with rates 4/15, 7/15, 8/15, 9/15; 4320 bit codewords with rates 1/5 and 1/2, 8640 bit codeword with rate 1/4). All other codes have been used before, e.g., in DVB-S2.
DVB-NGH uses two LDPC codes (4320 bits, rate 1/5 and 8640 bits, rate 1/2) for signalling the current configuration of the DVB-NGH system. The 8640 bits code is an extended LDPC code based on a code with 4320 bits and rate 1/2.
Standard |
DVB-NGH |
Next Generation broadcasting system to Handheld, physical layer specification (DVB-NGH) | |
Organization | ETSI |
Publication | 2012 (draft) |
Documents | ETSI EN 303 105 |
Applications | Terrestrial television broadcasting for handhelds |
LDPC Codes |
12 |
Block Length | Submatrix Size | Code Rates |
4320 | 72 | 1/5, 1/2 |
8640 | 72 | 1/4 |
16200 | 360 | 3/15, 4/15, 5/15, 6/15, 7/15, 8/15, 9/15, 10/15, 11/15 |
IEEE 802.11ac (WiFi)
The main objective of IEEE 802.11ac is to increase the throughputs of the previous IEEE 802.11 standards. Compared to IEEE 802.11n, the draft of IEEE 802.11ac allows for eight antennas (11n: four), 256-QAM modulation (11n: 64-QAM), and channel bandwidths of up to 160 MHz (11n: 40 MHz). The changes in the standard allow for a theoretical throughput of up to 7 Gbit/s. The LDPC codes are the same as in IEEE 802.11n.
Standard |
IEEE 802.11ac |
Organization | IEEE |
Publication |
Draft |
Documents | IEEE P802.11ac |
Applications | Local and Metropolitan Area Networks (WLAN/WMAN) |
IP Core | Creonic IEEE 802.11ac LDPC Decoder IP Core |
LDPC Codes | 12 |
Block Length | Submatrix Size | Code Rates |
648 | 27 | 1/2, 2/3, 3/4, 5/6 |
1296 |
54 | 1/2, 2/3, 3/4, 5/6 |
1944 |
81 | 1/2, 2/3, 3/4, 5/6 |
IEEE 802.11ad (WiGig)
IEEE 802.11ad is an amendment to IEEE 802.11-2007. Its intention is to modify the physical and MAC layer of the standard to enable a high throughput data transmission in the 60 GHz frequency band.
The standard defines four LDPC codes that are different from the codes defined in IEEE 802.11n and IEEE 802.11ac. LDPC coding is mandatory, no other coding scheme is specified. The increased submatrix size (42) of the parity check matrices relaxes the problem of achieving Gbit throughputs for such small block lengths in comparison to IEEE 802.11ac/n. In those standards the submatrix size is only 27 for a block length of 648 bits.
Standard |
IEEE 802.11ad |
Local and Metropolitan Area Networks – Specific Requirements Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) Specifications Amendment 5: Enhancements for Very High Throughput in the 60GHz Band |
|
Organization | IEEE |
Publication |
Draft (amendment to IEEE 802.11-2007) |
Documents | IEEE P802.11ad |
Applications | Local and Metropolitan Area Networks (WLAN/WMAN) |
IP Core | Creonic IEEE 802.11ad LDPC Decoder |
LDPC Codes | 4 |
Block Length | Submatrix Size | Code Rates |
672 | 42 | 1/2, 5/8, 3/4, 13/16 |
Learn more about the Creonic IP Core Portfolio!
Browse our website or
contact us
for more information.
